Features
- 6.5” weather treated woofer; 1” silk dome tweeter
- 105° conical DMT coverage
- 60 watt low-saturation and low-loss 70/100V transformers with 8Ω bypass
- Maximum peak SPL 116 dB (8 ohm bypass)
- DMT™ (Directivity Matched Transition) ensures smooth, uniform frequency response over the coverage area
- X-Mount™ system enables the loudspeaker to be easily installed and deployed at a variety of angles with no slippage over time
- Advanced voicing filter sets using QSC Intrinsic Correction™, available through either Q-SYS processing or CXD amplifier platforms
- Lightweight ABS enclosures offer long-term durability and lasting good looks
- Sealed input panel cover and powder coated aluminum grilles for added weather resistance
- Meets IEC60529 IP-54 for dust and splash resistance
- Available in black (RAL 9011) or white (RAL 9010)
- Complete EASE, CF2, CAD, and BIM information available online
| System Details | AD-S6T |
| Effective frequency range1 | 60 Hz – 20 kHz |
| Rated noise power / voltage2 | 150 watts / 35 volts (rms) |
| Broadband sensitivity3 | 89 dB SPL |
| Coverage angle (-6 dB) | 105° conical DMT |
| Directivity factor (Q) | 5 |
| Directivity Index | 7 dB |
| Maximum continuous SPL4 | 110 dB |
| Maximum peak SPL4 | 116 dB |
| Rated impedance | 8 ohms |
| Recommended amplifier power (loudspeaker “program” power) | 300 watts |
| Transformer taps | 70 V: 60, 30, 15, 7.5 W and 8Ω bypass 100V: 60, 30, 15 W and 8Ω bypass |
| HF transducer | 1” silk dome tweeter / 1” voice coil, horn loaded |
| LF transducer | 6.5” weather resistant paper cone woofer 1.5” / 38 mm voice coil |
| Input connector type | Euroblock connector with parallel output terminals |
| Enclosure material | Painted ABS polymer |
| Grille material | Powder coated aluminum |
| X-Mount material | Powder coated aluminum |
| Enclosure Details | |
| Ingress protection | IP-54 |
| Operating environment | Designed for indoor and outdoor use |
| Testing | The AD Series loudspeakers qualified for outdoor use using the following tests:
|
| Net weight | 13.6 lb / 6.2 kg |
| Product dimensions (HWD) inches | 14.4 × 8.5 × 8.5 |
| Product dimensions (HWD) mm | 365 × 215 × 215 |
| Weight | 9.50 lbs |
|---|
