• High peak output power with up to 1600 watts from the GXD 4 and a whopping 4500 Watts from the GXD 8.
• Power levels matched to the most popular loudspeakers and optimized for maximum real-world headroom into 4Ω and 8Ω speaker systems.
• Class D output stage with a universal power supply for high performance and efficiency.
• Extensive and powerful loudspeaker processing built in. Includes high and low-pass filters, 4-band parameteric EQ, limiting, and delay.
• E Series Entertainment System DSP Tunings are now available for GXD processing amplifiers:

             – Visit the GXD Firmware Updater to download and update

• Large LCD display simplifies amplifier setup and indicates amp status.
• Inputs: Parallel XLR and 1/4-inch TRS connectors for compatibility with any source while providing convenient loop-thru capability.
• Precision rotary encoders for gain and DSP parameter control.
• Outputs: Professional binding post and NL4 connectors (compatible with NL2) provide for mono and bi-amp speaker connections.
• Digital limiting automatically protects the amplifier from damage due to temperature rise or overdrive.
• Adjustable speaker protection to match your loudspeaker’s power and impedance.
• Front panel LEDs indicate signal presence, input overload, and amplifier clipping.

Tech Specs

• Number of Channels: 2
• Power Class: Class D
• Watts/Side @ 8 ohms: 800W (Continuous, both channels driven), 1500W (Dynamic, both channels driven)
• Watts/Side @ 4 ohms: 1200W (Continuous, both channels driven), 2250W (Dynamic, both channels driven)
• Inputs: 2 x XLR, 2 x 1/4″
• Outputs: 2 x Binding Posts, 2 x speakON
• DSP: Yes
• Filters: Yes
• Rack Spaces: 2U
• Height: 3.5″
• Depth: 10.2″
• Width: 19″
• Weight: 13.2 lbs.
• Manufacturer Part Number: GXD8
